AHI Forkift Series | Underground Special Truck

inteqral frame-type hydraulic support handling transporter is a new type of special vehicle, used for hydraulic support handling or transport over long distances, is an essental part of moder underground mining technology of auxiliary transportation equioment changed the traditional hydraulic support handling carier type,”U” type framework adopts whole frame and the compensation function of suspension system with the road, with heavy loading ability, compact structure, small turning radius and high reliability, etc.t can carry the extra long bracket, which has a wide range of adaptability.

The hydraulic support handlng vehicle is specihcally for the transportation and ong-distance transportation of hydraulic supports during the moving of coal mine underground fully mechanized mining faces, t subverts traditional design ideas and builds a new technoloay platform for the overallframework hvdraulic support hanaling vehicle by adopting a frame desian, multi axis, all wheel drive, all wheel steering and other technologies, it solves the shortcomings of traditional bracket handling vehicles and provides a new technological path for the development of bracket handling vehicles, makina it an essential auxiliary transportation eauipment for modern coal mining processes.

As part of EMAC, ConeMac integrates DCEC engines, provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

The company provides customers with full life cycle services, from design to power system supply, installation and commissioning, to after-sales service training and spare parts supply, as well as troubleshooting and overhaul technical support. This full range of services ensures that customer equipment maintains high reliability and long-term operating efficiency during use.

These comprehensive power systems and service capabilities enable Duramac to occupy an important position in the field of construction machinery and provide advanced solutions for future electrification trends.

Coming Soon

Coming Soon

Coming Soon

Coming Soon

AHI Forklift Series Underground Special Truck Main Feature

  • Flexible control: Overall frame design, fexible control.
  • High oriving efficiency: Driven by static hydraulic closed drive system, high effciency.
  • Reliable draking:Multi-mode hydraulic brake, safe and reliable braking.
  • Good oriving experience:Suspension system have road compensation function, good damping effect and driving comfort.
  • Hydraulic Transmission:Main function adopts hydraulic transmission technology, excellent explosion-proof performance.
  • Good Maintainability:The vehicle adopts modular design idea, good maintainability.

General Specifications of AHI Forklift Series Underground Special Truck

Vehicle Weight:32 – 55 t
Payload Class:25 – 130 t
No Load Speed:8 – 16 km/h
Full Load Speed:
5 – 16 km/h
AHI Underground Special Truck Forklift Series Catalogue

Product Model

Vehicle Weight

Payload Class

Product Model

Vehicle Weight

Payload Class

WX25J
33 t
25 tWC60Y
32 t
60 t
WC80Y
40 t
80 t
WC100Y
55 t
100 t
WC130Y
48 t
130 tWCJ12Y
22 t
12 t
WCJ60Y
55 t
60 t
WJX-3FB
17.5 t
3 t
WXP15
33 t
15 tWXP25
37 t
25 t
WXP45
58 t
45 t
WXP100
130 t
100 t
WXP130
143 t
130 t
——END——

AHI Forklift Series | Underground Special Truck Series

This is the list of all series of AHI Forklift Underground Special Truck Series.

WXP25

WXP25

Truck Model: WXP25
Oversize Dimension: 12300 * 2300 * 1800 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 37 t
Payload Class: 25 t

WXP25

WXP130

Truck Model: WXP130
Oversize Dimension: 15600 * 4000 * 2500 mm
Minimum Ground Clearance: 275 mm
Vehicle Weight: 143 t
Payload Class: 130 t

WXP25

WXP100

Truck Model: WXP100
Oversize Dimension: 14610 * 3910 * 2500 mm
Minimum Ground Clearance: 210 mm
Vehicle Weight: 130 t
Payload Class: 100 t

WXP25

WXP45

Truck Model: WXP45
Oversize Dimension: 12465 * 2850 * 1800 mm
Minimum Ground Clearance: 210 mm
Vehicle Weight: 58 t
Payload Class: 45 t

WXP25

WXP15

Truck Model: WXP15
Oversize Dimension: 11560 * 2760 * 1595 mm
Minimum Ground Clearance: 260 mm
Vehicle Weight: 33 t
Payload Class: 15 t

WXP25

WJX-3FB

Truck Model: WJX-3FB
Oversize Dimension: 7818 * 1900 * 1600 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 17.5 t
Payload Class: 3 t

WCJ60Y

WCJ60Y

Truck Model: WCJ60Y
Oversize Dimension: 10050 * 3100 * 2020 mm
Minimum Ground Clearance: 200 mm
Vehicle Weight: 55 t
Payload Class: 60 t

WCJ60Y

WCJ12Y

Truck Model: WCJ12Y
Oversize Dimension: 10450 * 1850 * 2150 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 22 t
Payload Class: 12 t

WC130Y

WC130Y

Truck Model: WC130Y
Oversize Dimension: 10500 * 4500 * 2600 mm
Minimum Ground Clearance: 280 mm
Vehicle Weight: 48 t
Payload Class: 130 t

WC130Y

WC100Y

Truck Model: WC100Y
Oversize Dimension: 8800 * 4500 * 2600 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 55 t
Payload Class: 100 t

WC130Y

WC80Y

Truck Model: WC80Y
Oversize Dimension: 8600 * 4000 * 2300 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 40 t
Payload Class: 80 t

WC130Y

WC60Y

Truck Model: WC60Y
Oversize Dimension: 7500 * 3700 * 2400 mm
Minimum Ground Clearance: 250 mm
Vehicle Weight: 32 t
Payload Class: 60 t

WC130Y

WX25J

Truck Model: WX25J
Oversize Dimension: 11200 * 2200 * 1800 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 33 t
Payload Class: 25 t
