HT3150 | 120T
The HT3150 mining truck adopts a 4×2 electric drive configuration. A diesel engine drives the main generator to generate three-phase alternating current (AC), which is converted into direct current (DC) by the rectifier unit inside the electric control cabinet. The frequency converter with IGBT (Insulated Gate Bipolar Transistor) as the core component in the electric control cabinet converts the rectified DC into three-phase AC with adjustable amplitude and frequency, thereby realizing the traction and speed regulation of the traction motor. The traction motor drives the reducer to transmit power to the tires for power transfer, and the vehicle’s forward and reverse movement is achieved by changing the direction of the magnetic field current of the traction motor.
EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.
EMAC Customer Interview-Thailand Engineering Company
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !EMAC Customer Interview-Indonesia Shipyard
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!Identification and Classification Report for Air Transport of Goods
Advantages of HT3150 Hual Truck
-
The HT3150 uses 4×2 electric drive. Its diesel engine, generator, and IGBT-based converter work together to deliver adjustable AC power, ensuring smooth traction and speed control. This system minimizes energy loss for reliable power transfer to tires, suiting heavy mining tasks.
-
Changing the traction motor’s magnetic field current enables easy forward/reverse switching. The reducer enhances power delivery, helping the truck handle steep slopes or rough mining terrains stably, even under full load.
-
Key components like IGBT converters and rectifier units are technologically mature. The integrated electric drive system has high stability, reducing failure risks and supporting long-term continuous operation in harsh mining environments.
-
The adjustable AC power allows precise speed regulation for different mining scenarios. Simple forward/reverse control and smooth power output make the truck easy to operate, improving work efficiency for drivers.
Technical Specifications
| Truck Model： |
HT3150 |
| Drive Model: | 4 * 2 |
| External Dimensions: | 12570 * 7530* 6100 mm |
| Wheelbase: | 5300 mm |
| Front/Rear Track: | 5106 / 4580 mm |
| Maximum Tipping Angle of Tipper (°): |
50 |
| Vehicle Weight: | 120000 kg |
| Payload: |
136000 kg |
| Min. Ground Clearance: | ≥ 600 mm |
| Hydraulic Oil Tank Capacity: | ≥ 650 L |
| Rated Power： | ≥ 1194 kW |
| Max.Input Torque： | ≥ 6500 mm |
| Rated Speed： | 1800 RPM |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T,L/C |
Hual Truck Model |
Payload Class |
Vehicle Weight |
External Dimensions |
Min. Ground Clearance |
| HT3100 | 90t | N/A | 11990*6580*6100 mm | 600 mm |
| HT3100B | 90t | N/A | 11990*6580*6102 mm | 600 mm |
| HT3100-LNG | 90t | N/A | 11990*6580*6101 mm | 600 mm |
| HT3110E | 110 t | 90 t | 11610 * 6600 * 6420 mm | ≥600 mm |
| HT3130 | 120 t | 110 t | 12120 * 7530 * 6100 mm | 600 mm |
| HT3143 | 130 t | 110 t | 11840 * 7530 * 6070 mm | 600 mm |
| HT3150 | 136t | 120t | 12200 * 7000 * 6300 mm | 620 mm |
| HT3150-LNG | 136 t | 120 t | 12120 * 7530 * 6100 mm | 600 mm |
| HT3240 | 220 t | 165 t | 14500 * 7500 * 6910 mm | 800 mm |
| HT3363 | 363 t | 237 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT5220 | 220 t | 110 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT5240 | 220 t | 165 t | 15000 * 7200 * 6980 mm | 800 mm |
| ——END—— | ||||
Dimension Information of HT3150 Electric Wheel Mining Dump Vehicle |
|||
| External Dimensions | 12200 * 7000 * 6300 mm（Excluding rearview mirrors） | Wheelbase (mm) | 5200 |
| Front/Rear Track (mm) | 5200/4300 | Min. Ground Clearance (mm) | ≥620 |
| Maximum Height with Tipper Lifted (mm) | ≤12000 | Maximum Tipping Angle of Tipper(°) | 52 |
Mass Parameters ofHT3150 Electric Wheel Mining Dump Vehicle |
|||
| Payload (kg) | 136000 kg | Flat Loading (m³) | 55 |
| Heaped Loading 2:1 (m³) | 73 | LNG Tank Capacity (L) | ≥1500 |
| Hydraulic Oil Tank Capacity (L) | ≥650 | Front Axle/Rear Axle (Unloaded) (%) | 50/50 |
| Front Axle/Rear Axle (Loaded) (%) | 33/67 | ||
| ——END—— | |||
Main Configuration of HT3150 Electric Wheel Mining Dump Vehicle |
|||
| Engine – Rated Power (kW) | ≥1194 | Engine – Maximum Torque (Nm) | ≥6500 |
| Engine – Rated Speed (rpm) | 1800 | Traction Converter Cabinet – Voltage Class (VAC) | 1140 |
| Traction Converter Cabinet – Net Output Power (kW) | ≥1000 | Traction Converter Cabinet – Cooling Method | Air Cooling |
| Main Generator – Voltage Class (VAC) | 1140 | Main Generator – Rated Output Power (kVA) | ≥1190 |
| Main Generator – Rated Output Current (A) | 500 | Traction Motor – Output Power (kW) | raction Power ≥2×500; Braking Power ≥2×900 |
| Traction Motor – Maximum Speed (rpm) | ≥3500 | Traction Motor – Maximum Traction Torque (Nm) | ≥4500 |
| Traction Motor – Cooling Method | Air Cooling | Reducer – Reduction Ratio | 30.71 |
| Reducer – Service Braking Method | Full-Disc Dry Braking | Reducer – Parking Braking Method | Full-Disc Dry, Spring-Released |
| Braking Resistor – Continuous Braking Power (kW) | ≥2×1050 | Braking Resistor – Maximum Braking Power (kW) | ≥2×700 |
| Braking Resistor – Rated Operating Voltage (VDC) | 1850 | Central Lubrication | Equipped |
| Automatic Fire Suppression | Equipped | ||
Performance Parameter of AHI HT3150 Electric Wheel Mining Dump Vehicle |
|||
| No-load Maximum Speed (km/h) | ≥50 | Full-load Maximum Speed (km/h) | ≥45 |
| Maximum Climbing Gradient (Full-load) (%) | 16 | Rated Climbing Gradient (Full-load) (km/h) | 8%, ≥13km/h |
| 30km/h Acceleration Time (Full-load) (s) | ≤23 | Maximum Holding Gradient (Full-load) (%) | 20 |
| 30km/h Braking Distance (m) | ≤22 | Dump Body Lifting Time (s) | ≤22 |
| Dump Body Lowering Time (s) | ≤20 | Minimum Turning Diameter (m) | ≤28 |
| ——END—— | |||
Can Quality be Guaranteed?
(1)Strict production process and testing: The production process adopts advanced manufacturing technology and strict quality management system to ensure that each engine is precisely assembled and tested. Komatsu will conduct various performance tests, such as power test, emission test, etc., to ensure the running stability and reliability of the engine.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right engine to match your machine. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
