HT3100 | 90T
The HT3100 mining truck adopts a 4×2 electric drive configuration. The engine drives the main generator to produce three-phase alternating current, which is converted into direct current by the rectifier unit in the electric control cabinet. The frequency converter with IGBT as the core component in the electric control cabinet converts the rectified direct current into three-phase alternating current with adjustable amplitude and frequency, realizing the traction and speed regulation of the traction motor.
The traction motor drives the reducer to transmit power to the tires for power transfer. The forward and backward movement of the vehicle is achieved by changing the direction of the magnetic field current of the traction motor.
EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.EMAC Customer Interview-Thailand Engineering Company
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !EMAC Customer Interview-Indonesia Shipyard
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!Identification and Classification Report for Air Transport of Goods
Advantages of AHI HT115 Wide-body Mining Truck
The HT3100 mining truck features highly efficient power transmission. Its electric drive system eliminates multiple mechanical components like clutches and gearboxes, minimizing energy loss during power transfer. The IGBT-based frequency converter precisely adjusts current amplitude and frequency, ensuring the traction motor operates in an optimal efficiency range, especially suitable for heavy-load starting and long uphill climbs in mining environments.
It offers exceptional operational flexibility. Direction reversal via altering the traction motor’s magnetic field current eliminates mechanical shifting, enabling faster response. The 4×2 electric drive with accurate speed regulation adapts to varying road slopes and loads, enhancing passability on muddy or bumpy surfaces common in mines.
The truck boasts superior structural reliability. With fewer mechanical moving parts in its electric drive system, components like reducers and traction motors have lower failure rates than traditional transmissions. The integrated design of rectification and frequency conversion units in the electric control cabinet reduces line failure risks.
It provides cost-saving maintenance advantages. The simplified electric drive structure reduces repair frequencies in harsh mining conditions. Core components such as IGBTs exhibit excellent high-temperature resistance and overload capacity, extending the mean time between failures and lowering long-term maintenance costs significantly.
Technical Specifications
| Truck Model： | HT3100 |
| Drive Model: | 4 * 2 |
| External Dimensions(L*W*H): | 11990*6580*6100mm(No rearview mirror) |
| Wheelbase: | 5000 mm |
| Front/Rear Track (mm): | 5145 / 4185 |
| Maximum Tipping Angle of Tipper (°): | 50 |
| Payload: | 90000 kg |
| Min. Ground Clearance: | ≥ 600 mm |
| Diesel Tank Capacity (L)： | ≥ 1300 L |
| Hydraulic Oil Tank Capacity (L): | ≥ 650 L |
| Rated Power： | ≥ 900 kW |
| Max.input torque： | ≤11700 mm |
| Rated Speed： | 1900 RPM |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T,L/C |
Hual Truck Model | Payload Class | Vehicle Weight | External Dimensions | Min. Ground Clearance |
| HT3100 | 90t | N/A | 11990*6580*6100 mm | 600 mm |
| HT3100B | 90t | N/A | 11990*6580*6102 mm | 600 mm |
| HT3100-LNG | 90t | N/A | 11990*6580*6101 mm | 600 mm |
| HT3110E | 110 t | 90 t | 11610 * 6600 * 6420 mm | ≥600 mm |
| HT3130 | 120 t | 110 t | 12120 * 7530 * 6100 mm | 600 mm |
| HT3143 | 130 t | 110 t | 11840 * 7530 * 6070 mm | 600 mm |
| HT3150 | 136t | 120t | 12200 * 7000 * 6300 mm | 620 mm |
| HT3150-LNG | 136 t | 120 t | 12120 * 7530 * 6100 mm | 600 mm |
| HT3240 | 220 t | 165 t | 14500 * 7500 * 6910 mm | 800 mm |
| HT3363 | 363 t | 237 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT5220 | 220 t | 110 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT5240 | 220 t | 165 t | 15000 * 7200 * 6980 mm | 800 mm |
| ——END—— | ||||
Dimension Information of HT3100 Wide-body MiningTruck | |||
| Overall Dimensions (L×W×H) (mm) | 11990×6580×6100mm（Excluding rearview mirrors） | Wheelbase (mm) | 5000 |
| Front/Rear Track (mm) | 5145/4185 | Minimum Ground Clearance (mm) | ≥600 |
| Maximum Height with Tipper Lifted (mm) | ≤11700 | Maximum Tipping Angle of Tipper (°) | 50 |
Mass Parameters ofHT3100 Wide-body Mining Truck | |||
| Rated Payload (kg) | 90000kg | Flat Loading (m³) | 44.5 |
| Heaped Loading 2:1(m³) | 60 | Diesel Tank Capacity (L) | ≥1300 |
| Hydraulic Oil Tank Capacity (L) | ≥650 | Front Axle/Rear Axle (Unloaded) (%) | 50/50 |
| Front Axle/Rear Axle (Loaded) (%) | 33/67 | ||
| ——END—— | |||
Main Configuration of HT3100 Wide-body Mining Truck | |||
| Engine – Rated Power (kW) | ≥900（Weichai） | Engine – Maximum Torque (Nm) | ≥4955 |
| Engine – Rated Speed (rpm) | 1900 | Traction Converter Cabinet – Voltage Class (VAC) | 1140 |
| Traction Converter Cabinet – Net Output Power (kW) | Traction Power ≥900; Braking Power ≥1800 | Traction Converter Cabinet – Cooling Method | Air Cooling |
| Main Generator – Voltage Class (VAC) | 1140 | Main Generator – Rated Output Power (kVA) | ≥900 |
| Main Generator – Rated Output Current (A) | 456 | Traction Motor – Output Power (kW) | Traction Power ≥360; Braking Power ≥760 |
| Traction Motor – Maximum Speed (rpm) | ≥3500 | Traction Motor – Maximum Traction Torque (Nm) | ≥3800 |
| Traction Motor – Cooling Method | Air Cooling | Reducer – Reduction Ratio | 33.85 |
| Reducer – Service Braking Method | Full-Disc Dry Braking | Reducer – Parking Braking Method | Full-Disc Dry, Spring-Released |
| Braking Resistor – Continuous Braking Power (kW) | ≥2×600 | Braking Resistor – Maximum Braking Power (kW) | ≥2×700 |
| Braking Resistor – Rated Operating Voltage (VDC) | 1850 | Central Lubrication | Equipped |
| Automatic Fire Suppression | Equipped | ||
Performance Parameter of AHI HT115EV Wide-body Mining Truck | |||
| No-load Maximum Speed (km/h) | ≥50 | Full-load Maximum Speed (km/h) | ≥40 |
| Maximum Climbing Gradient (Full-load) (%) | 16 | Rated Climbing Gradient (Full-load) (km/h) | 8%, ≥11km/h |
| 30km/h Acceleration Time (Full-load) (s) | ≤23 | Maximum Holding Gradient (Full-load) (%) | 20 |
| 30km/h Braking Distance (m) | ≤22 | Dump Body Lifting Time (s) | ≤22 |
| Dump Body Lowering Time (s) | ≤25 | Minimum Turning Diameter (m) | ≤24.5 |
| ——END—— | |||
Can Quality be Guaranteed?
(1)Strict production process and testing: The production process adopts advanced manufacturing technology and strict quality management system to ensure that each engine is precisely assembled and tested. Komatsu will conduct various performance tests, such as power test, emission test, etc., to ensure the running stability and reliability of the engine.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right engine to match your machine. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
